IEC61032 IEC 60529 IP4X Test Probe D with 1N Force

Article NO.: LX-IP40T

Basic Introduction:

1,According to: IEC61032:1997/IEC60529:2001 AND UL.

2,P4X Test Probe D ( Test Probe D) is a necessary appliance for domestic and similar electrical appliance of against electric shock protection test.

Technical parameters:

1, Test Probe Length :100mm

2, Test Probe Diameter:1.0mm

3, Dam- sphere Diameter:35mm

4, Handle Diameter:10mm

5, Handle Length 100mm

6, According to IEC61032 figure 4 (the Test probe D)

Application:

1, Standard test refers to the joint part can't touch the live parts or approachi to the hazardous parts, 30mm circular baffle cannot enter.

2, In the test requirement for preventing from approaching to the hazardous parts, Test Probe D need to exert a thrust 1±0.1N.
